Product Advantage
Advanced Comfort Suite
Integrated heating and massage system alleviates patient anxiety and enhances the perception of premium care.
Trendelenburg Ergonomics
Synchronized seat-tilt and backrest movement prevents patient sliding and optimizes blood flow during long procedures.
Nappa Leather Artistry
Hand-stitched Nappa leather upholstery offers an elite tactile experience and a sophisticated aesthetic for high-end clinics.
Standard Features
·AJ18 hybraulic chair with comfort kit，
·with 3 programmable positions,
·Double articulating headrest,
·Swing up/down iron armrest,
·Cast iron chair frame,
·Iron backrest stand,
·Cast aluminum base,
Wide backrest, upgraded fiber leather,
60 degrees seat rotation, chair safety switch,
One touchpad, Foot control
Beyond luxury dentist's control head, Standard touchpad,
Cast aluminium delivery head base, double pivot delivery head, with 3 auto H.P. control,
Individual water coolant controls,
Master handpiece air coolant adjustment,
Asepsis handpiece tubing,
Master on/off switch,1 doctor syringe, Wet/Dry foot control,
Stainless steel tray with non-slip pad, Flex arm air brake switch
Beyond 300/301 Post mounted utility (PMU) with silver side box,
City water/bottled system, Water outlet and air QD,
Swing assistant tray with touchpad,
Solids collector,
2 HVE,1SE,1 syringe,
Alumium base Junction box with air/water filters,regulators, master shut-off valves,
5 ft umbilical
Post mount LED light with sensor control, 3 level intensity adjustment
Accessories Options
A121963
Bien Air MCX Built In System Without Touchpad
A121973
Bien Air MCX Built In System With Touchpad
A121997
Bien Air MX2 Built In System Without Touchpad
A121998
Bien Air MX2 Built In System With Touchpad
A121532
HP Fiber Optic system with 1 tubing (6 pin)
A121533
HP Fiber Optic system with 2 tubings (6 pin)
A120403
Built in scaler with LED
8400387
Scaler with LED Handpiece
A120301
LED.G curing light (Build-in Type) 110V
Technical Parameters
| Environmental requirements | Ambient temperature 41F～104F Humidity≤80% |
| Electrical requirements | AC110V±22V 50HZ, 60HZ |
| Hydraulic pump run time | Intermittent operation 2min On /18min Off |
| Weight | 366lbs Dimensions |
| Max patient load | 550lbs |
Beyond400 Delivery System
① Ambient temperature：5 ℃～40 ℃；
② Relative Humidity：≤ 80％；
③ Nominal Voltage：AC110 V±22 V；
④ Nominal Frequency：60 Hz±1 Hz；
⑤ Water Pressure：29 psi～58 psi；
⑥ Input air pressure 72.5 psi~101.5 psi , Air flow ≥50 L/min
Light Specifications
Powerinput:AC24V
llluminance: 8000-40000 lux
Color temperature
White light: 5200k
Yellow Light: 3500k
Composite Light: 4400k-5200k
Powerconsumption:<10W
