Product Advantage
Cast Aluminum Architecture
All-aluminum chair frame ensures maximum corrosion resistance and structural integrity while reducing overall equipment weight.
Ultra-Thin Visibility
The ultra-thin cast aluminum backrest allows for closer patient proximity and enhanced legroom for the operator.
Intelligent Integration
Designed for high-efficiency clinical control systems, streamlining instrument access and improving procedural flow.
Standard Features
• AJ16 Luxury hydraulic chair, with 3 programmable positions,
• Double articulating headrest, Swing up/down armrest,
• Wide backrest, upgraded fiber leather, Cast iron chair frame,
• Cast aluminium backrest stand, Cast aluminium base,
• 60 degrees seat rotation, chair safety switch,
• One touchpad, Foot control
• Swing Beyond dentist's control head, Standard touchpad,
• Cast aluminium delivery head base, double pivot delivery head,
3 auto H.P. control, Individual water coolant controls,
• Master handpiece air coolant adjustment, Asepsis handpiece tubing,
• Master on/off switch, 1 doctor syringe,
• Wet/Dry foot control, Stainless steel tray with non-slip pad,
• City/bottled water system, 5 ft umbilical,
• Junction box with air/water filters, regulators, master shut-off valves,
• Chair mounted swing rear assistant vacuum package,
• Assistant touchpad, Water outlet and air QD on assistant tray,
• Solids collector, 2 HVE,1SE, 1 syringe
Swing mount LED light with sensor control, 3 level intensity adjustment
Accessories Options
A121963
Bien Air MCX Built In System Without Touchpad
A121973
Bien Air MCX Built In System With Touchpad
A121997
Bien Air MX2 Built In System Without Touchpad
A121998
Bien Air MX2 Built In System With Touchpad
A121532
HP Fiber Optic system with 1 tubing (6 pin)
A121533
HP Fiber Optic system with 2 tubings (6 pin)
A120403
Built in scaler with LED
8400387
Scaler with LED Handpiece
A120301
LED.G curing light (Build-in Type) 110V
Technical Parameters
| Environmental requirements | Ambient temperature 41F～104F Humidity≤80% |
| Electrical requirements | AC110V±22V 50HZ, 60HZ |
| Hydraulic pump run time | Intermittent operation 2min On /18min Off |
| Weight | 366lbs Dimensions |
| Max patient load | 550lbs |
Beyond400 Delivery System
① Ambient temperature：5 ℃～40 ℃；
② Relative Humidity：≤ 80％；
③ Nominal Voltage：AC110 V±22 V；
④ Nominal Frequency：60 Hz±1 Hz；
⑤ Water Pressure：29 psi～58 psi；
⑥ Input air pressure 72.5 psi~101.5 psi , Air flow ≥50 L/min
Standard Features
Powerinput:AC24Vllluminance: 8000-40000 lux
Color temperatureWhite light: 5200kYellow Light: 3500kComposite Light: 4400k-5200kPowerconsumption:<10W
