Product Advantage
Hydraulic Precision
Smooth, silent vertical travel with high lift capacity.
Unshakeable Stability
Reinforced cast-iron frame eliminates vibrations for precise operations.
Dynamic Flexibility
60° rotation for versatile positioning and expanded operator space.
Standard Features
·AJ15 hydraulic chair with 3 programmable positions,
·Double articulating headrest, Swing up/down armrest,
·Narrow backseat, upgrade fiber leather,
·Cast iron chair frame,Steel backrest stand, Steel base plate,
·60 degrees seat rotation, chair safety switch,
·One touchpad,Foot control
·Swing Classic dentist's control head with 3 auto H.P.control,
·Individual water coolant controls,
·Master handpiece air coolant adjustment,
·Asepsis handpiece tubing,
·Master on/off switch, 1 doctor syringe,
·Wet/Dry foot control,Stainless steel tray with non-slip pad,
·City/bottled water system,5ft umbilical,
·Junction box with air/water filters, regulators, master shut-off valves,
·Chair mounted swing rear assistant vaccum package,
·Water outlet and air QD on assistant tray,
·Solid collecteor,
·2 HVE,1 SE,1 syringe
·Swing mount LED light with sensor control, 3 level intensity adjustment
Accessories Options
A121963
Bien Air MCX Built In System Without Touchpad
A121973
Bien Air MCX Built In System With Touchpad
A121997
Bien Air MX2 Built In System Without Touchpad
A121998
Bien Air MX2 Built In System With Touchpad
A121532
HP Fiber Optic system with 1 tubing (6 pin)
A121533
HP Fiber Optic system with 2 tubings (6 pin)
A120403
Built in scaler with LED
8400387
Scaler with LED Handpiece
A120301
LED.G curing light (Build-in Type) 110V
Technical Parameters
| Environmental requirements | Ambient temperature 41F～104F Humidity≤80% |
| Electrical requirements | AC110V±22V 50HZ, 60HZ |
| Hydraulic pump run time | Intermittent operation 2min On /18min Off |
| Weight | 364lbs |
| Max patient load | 550lbs |
Classic 200 Delivery System
Ambient temperature：5 ℃～40 ℃；
Relative Humidity：≤ 80％；
Nominal Voltage：AC110 V±22 V；
Nominal Frequency：60 Hz±1 Hz；
Water Pressure：29 psi～58 psi；
Input air pressure 72.5 psi~101.5 psi , Air flow ≥50 L/min
Light Specifications
Powerinput:AC24V
Illuminance: 8000-25000 lux
Color temperature：5000-5500k
Power consumption:<15W
